cfe567 No.480811
Wew, my favourite thread didn't survive these turbulent days. But it's an image board, in a way or other it was destined to disappear. This time we shouldn't even limit the thread to just weapon designs, throw in everything you've got.
To start it off, in the vein of giving belt-feds to everyone here is this extremely autistic idea: ammo belt bandoliers. Basically instead of an ammo box you have a belt with ~200 cartridges in a bandolier you swing over your shoulder, and the weapon feeds from it. Of course it shouldn't be just a piece of canvas, but something that actually protects the belt, has some rollers in it to allow seamless feeding, is padded to make it more comfortable, etc, etc. Then it just needs a feed chute placed about next to the hip. I think it would actually work better with bullpups.
Now, officially an average infantryman in the US Army carries 210 rounds in 7 mags and have an ammo box with a 200 round belt for the SAW gunner. Instead with this system a right handed soldier would carry a bandolier over his left shoulder to feed his weapon, and an other one over his right shoulder to toss it to the SAW gunner if he is running low. Of course the SAW gunner should carry his own 800 rounds in one of those fancy ammo bags.
Bonus: some Czechnology, the URZ family of weapons. From basic service rifle to GPMG everything is here, and all of them are belt-fed. It was chambered for 7.62 NATO, because they made them for export. The feed system is quite interesting, they managed to combine magazines with belts. Take a look at the patent: http://www.google.com/patents/US3507186
cfe567 No.480868
cfe567 No.480871
>>480811
>3rd pic
Now all you need is to connect that to the ammo production lines. Never reload.
cfe567 No.480893
How does one go about designing a gun? Is it feasible for someone without mechanical engineering skills to do?
cfe567 No.480896
>>480893
Yeah. Plenty of gun designers weren't engineers. Ronnie Barrett being a more modern example. You might want to consult a machinist regarding the safety side of things. Be careful.
cfe567 No.480897
>>480893
>How does one go about designing a gun?
How does one go about chewing food? Just draw shit.
>Is it feasible for someone without mechanical engineering skills to do?
Yes. But you don't need to invent guns yourself, there's plenty of information on the internet about how gun parts and ammunition work.
cfe567 No.480915
i tought of something for an air rifle that had a crank and everytime you rotated it once it would cock and drop a shot
basically a semi auto air rifle
cfe567 No.480917
I've been wanting to build a derringer from scratch for awhile and I'm pondering a sort of recoil operated action. Still a single shot, but casing ejected upon firing maybe like an open bolt design or something. It came about not so much to speed up reloading as a way to mitigate percieved recoil through redirection
I'm pretty sure its really stupid so I'll probably just go with a simple pivot action. Maybe play with bore axis in relation to grip like the Mateba and Rhino
cfe567 No.480927
I want to make a muzzleloading gunpowder shotgun with oil hardened black iron pipe
cfe567 No.480934
>>480893
step 1. design the externals
cfe567 No.480940
cfe567 No.480990
>>480915
At a time I was very interested in some alternative reality where air rifles and spring-powered crossbows became much better than muzzle loaders during the industrial revolution, and so instead of smokeless powder people concentrated on those weapons. And also steam power became a lot more widespread, so every nearly every household had at least a small one, and vehicles were powered by steam instead of internal combustion. So, yeah, basically steampunk without the baggage all the retarded shit that makes steampunk so horrible. But for such a world to work you'd need every second man to be a skilled machinist, and not even the most autistic Asian population could make that work.
Still, look at this for inspiration:
https://en.wikipedia.org/wiki/Zadoc_Dederick
https://en.wikipedia.org/wiki/Girandoni_air_rifle
Anyway, what I really want to say is that you can make air rifles a bit more potent by coating the projectiles in a combustible oil. There are actually commercially available oils out there. Combine that with your idea, and you could make something surprisingly effective, at least by the standards of the Napoleonic wars. Imagine some mad inventor moving down whole rows of infantry at the beginning of the 19th century with one such weapon.
cfe567 No.480999
I want to know how to fix this further
cfe567 No.481003
YouTube embed. Click thumbnail to play.
>>480999
Something like a reversed and upside-down Mars pistol?
cfe567 No.481007
>>480893
its just a thing hitting other thing that makes boom. niggers can do it
cfe567 No.481018
>>480893
I've got a bunch of designs for subguns lying around. In all honesty get some balsa wood and learn how to throw a trigger group together and then move on to other parts like bolts and such.
cfe567 No.481052
While the .30 carbine and 10mm magnum (my fingers always want to double the zero. That would make it a 100m handgun. Could be awesome, actually.) are way-cool,
if we're going for ridiculous, we need .454 casull, and whatever anti-material round the Jackal eats.
I guess I won't post FlutterBat-as-Alucard this time around. Maybe a battlesaddle later … could have a vehicle agumented with an externally mounted rifle, fireable from the steering wheel.
cfe567 No.481090
>>481052
Now that I think about it, wouldn't a simple revolver rifle chambered for .460 S&W and designed to accept moonclips be a surprisingly versatile hunting weapon? It would work with .460 S&W, .454 Casull, .45 Colt, .45 Schofield, .45 APC and even .410 bore. So in theory you could hunt bears and squirrels with the same gun, not to mention all the other prey that are between those two mammals in size.
cfe567 No.481138
6mm lee modernized with new bullets and powder.
https://en.wikipedia.org/wiki/6mm_Lee_Navy
cfe567 No.481153
>>481138
that's not a bullet, it's a dildo.
cfe567 No.481156
>>481097
>lets shoehorn as many untested technologies into one rifle as possible
>then make the design more complex to force people to buy entire actions every time they malfunction
Jesus fucking christ HK….
cfe567 No.481200
cfe567 No.481247
>>481200
and weighed 16kg; somehow I always get those two mixed up.
13mm gold jacketed spire point rounds each individually blessed by a priest.
Still not as insane as the police girl's "rifle"
cfe567 No.481595
>>481247
Talking about big guns, what about a new, revamped PTRD but with the gas system of the AEK-91?
cfe567 No.481677
>>481595
Might as well change up a KPV before you hack into a PTRD.
cfe567 No.481712
>>481677
I was thinking more like making new PTRDs rather than hacking old ones.
And weren't the kurds making 14.5 bolt rifles with KPV barrels?
cfe567 No.481718
>>481712
I don't know, but scroll down to the M3 here: http://www.hungariae.com/Gepard.htm
cfe567 No.481720
>>481718
Also: http://archive.is/2TrL9
>In terms of future product development, they are currently working on a magazine-fed, semi-automatic rifle that shares the same long recoil technology as the GM6 Lynx but fires the much larger 14.5x114mm Russian round.
>This round has twice the energy at 32,000 Jules than a .50BMG at 15,000 Jules with a 3km (1.9 mile) effective range. This round makes the .50BMG looks small! Interestingly, the 5 round magazine is parallel to the pistol grip. The prototype that they had shown me is quite light weight at just 17kg without ammo and scope. Most of the 14.5mm bolt action rifles in the market weight around 23kg (51lbs) empty. This is really a handheld artillery.
cfe567 No.481726
cfe567 No.481730
cfe567 No.481733
>>481730
if it shot you would you die?
cfe567 No.481764
>>481733
At that point the question is whether the random bits of organic matter can be considered a person or not.
cfe567 No.481766
>>481764
Well we consider Brazilians people.
cfe567 No.481767
>>480893
1.) Decide what needs to die
2.) Attach things to other things until you can kill it
cfe567 No.481768
>>481755
That's a photoshop.
cfe567 No.481769
>>481767
Brazillian engineers are the best.
cfe567 No.481774
cfe567 No.481799
>>480893
Iterative design. Prototype. Test. Revise. Repeat.
Problem is, this takes a lot of time and work, and it's entirely possible you're going to make a lot of parts that don't work before you make one that does, and even more before you make one that works well, especially for unconventional ideas. Furthermore, you're never going to be sure if a design is entirely optimal in terms of material selection, proportions, tolerances, and god only knows what else, which may or may not bother you.
>>480990
>And also steam power became a lot more widespread, so every nearly every household had at least a small one
You mean like back in the day how every building had a boiler in the basement for steam heat and you would get a bushel of coal on your doorstep each morning with the milk and paper? Combine the ubiquity of having a couple bar of dry steam on tap with the utility of having a hit-and-miss engine for running water pumps, farm equipment, electric generators, household appliances, any sort of wood or metal working power tools, medical devices for treating 'hysteria' in women, and god knows what else? Yeah, I can see that.
>and vehicles were powered by steam instead of internal combustion
So basically the UK up through the 30's and 40's? Steam cars were preferred to internal combustion due to ease of use, lighting a gas burner being a lot easier than crank starting a gas engine, and steam trucks or tractors were often the only way to do any heavy hauling.
>you'd need every second man to be a skilled machinist
So basically the UK up through the 40's and 50's, where an engine lathe and drill press were considered essential equipment for any garage workshop?
cfe567 No.481801
>>481090
Make it a gas seal action with an integral suppressor and we've got a winner.
Now that I think about it, why did the gas seal design never take off? I know the Nagant had weird proprietary cartridges and an atrocious trigger pull, but neither of those faults had anything to do with the action, right?
>sage because doublepost
cfe567 No.481810
>>481755
>nice dubs
I WANT THAT RIFLE, GIMME GIMME GIMME
cfe567 No.481815
>>481801
IIRC the gas seal was much of what caused the horrible trigger because you have to move the whole cylinder back/forward against a seal with each trigger pull.
It might be possible to make a revolver that has a gas seal but operates similar to the chiappa rhino which would keep the trigger from having to do so much work.
cfe567 No.481820
>>481801
>>481815
So I just found this.
>Abstract
>In a revolver having a frame, carrying a barrel and a revolving cylinder having multiple cartridge chambers therearound, the improvement comprising: a) a sliding sleeve positioned over an inner end portion of the barrel, said end portion of the barrel and inner diameter of the sliding sleeve closely mated; and, a) a sliding sleeve positioned over an inner end portion of the barrel, said end portion of the barrel and inner diameter of the sliding sleeve closely mated; and, b) said sliding sleeve having a front face having a central opening therethrough having an inner diameter nominally equivalent to marginally larger than, a bore through the barrel. Whereafter firing, the sliding sleeve is instantaneously driven back contacting its front face with the revolving cylinder, thereby eliminating any gap between the revolving cylinder and the barrel, preventing exploding gas from escaping therethrough, and substantially increasing bullet discharge velocity and energy.
cfe567 No.481839
YouTube embed. Click thumbnail to play.
>>481799
>>481799
>Combine the ubiquity of having a couple bar of dry steam on tap with the utility of having a hit-and-miss engine for running water pumps, farm equipment, electric generators, household appliances, any sort of wood or metal working power tools, medical devices for treating 'hysteria' in women, and god knows what else? Yeah, I can see that.
Exactly. But imagine if it happened right at the start of the industrial revolution, and instead of massive urbanization you'd first have every blacksmith at the end of a village replaced by a machinists who wants to make crazy new inventions, and then technology progresses along the lines of "if you can't build it in a shed with 2-3 good friends, then it's either a miraculous machine too complicated for the average person, or shit, completely shit". I mean, even the bongs didn't build their Enfields in small workshops all over the country.
>So basically the UK up through the 30's and 40's?
Kind of, but again, more ubiquitous. As far as I know the average person didn't have a car well until the 50s and 60s, and unfortunately those weren't steam powered.
>So basically the UK up through the 40's and 50's, where an engine lathe and drill press were considered essential equipment for any garage workshop?
Indeed, but a workshop powered by its own steam boiler wasn't considered essential for a house, right?
Basically what I wanted to avoid is that terrible thing called steampunk. Usually it's either the modern world with in 19th century clothing, or the 19th century with modern or even sci-fi technology. Both of them are terrible when the world building is supposedly around specific forms of technology. So in a way it too would be science-fiction, just instead of a possible future it would focus on an alternative past.
cfe567 No.481841
>>481801
>Make it a gas seal action with an integral suppressor and we've got a winner.
That's simple, just turn it into an autorevolver by copying the Jackhammer's blow forward action. The layout should follow the Mars revolver, so it would be a "bullpup". I've been even thinking about the design and the possible ways of manufacturing the individual parts. The only problem is that I'm not sure if firing all these wildly different cartridges is mechanically safe and sound, even with an adjustable gas port.
cfe567 No.481855
>>481733
It would be rather painful
cfe567 No.481881
>>481820
Optimistic as fuck, seeing as there's no way to create a perfect seal without the brass extending past the cylinder and into the barrel.
cfe567 No.481928
>>481769
Even bought the camo micro DLC.
cfe567 No.482010
>>481766
If abos are your point of reference, maybe.
cfe567 No.482037
>>481801
Autoloaders appeared pretty much concurrently with the Nagant gas seal system, and they won.
cfe567 No.482155
Got an idea for a pistol firing cased telescopic ammo after thinking about the Pancor Jackhammer's action a bit:
>barrel is fixed in place, there is a gas seal where the slide ends
>there are two gas ports cut into the barrel behind the gas seal
>there is a second gas seal behind the ports, this one is fixed to the slide
>when the gun is fired the slide (that is pretty much an annular gas piston now) slides back, revealing the gas ports and letting the gases out
>bolt is also fixed in place, the slide only actuates the moving chamber
For simplicity's sake the barrel's gas seal should be fixed to a muzzle device instead of the barrel. This way you'd just have to remove the muzzle device and move the slide forward to get it off the gun. And instead of threads the muzzle device should be affixed via a bayonet mount.
Now, I don't have an idea for the chamber, but our resident Finn already came up with this action. I don't really understand the geometry, so I'd rather not try to explain it. He said it's similar to the Kriss Vektor's bolt, but with the magazine laying parallel to the barrel.
cfe567 No.482161
>>482160
You'd need a different magazine and feed design, the whole system is built around the particular taper/length/size of the 5.7.
If we're going this route, I want a P90 in 9x25 Dillon.
cfe567 No.482166
YouTube embed. Click thumbnail to play.
>>482155
Ah. I do remember this one. I was suppose to get in detail with the action but I never did.
This is a composite pistol ("Lynx pistol") which uses CTA-style ammunition which seals the chamber's front to the barrel by expanding. As the exact opposite to my usual designs this was a vision of the ambidextrious future police service pistol with functions like removable and pistol specific trigger("trigger key") which also acts as a fire control. So it's a "robocop" pistol of sorts. With my lack of time and inspiration inducing spinach I doubt I'll return to finish it. But if it's of any interest then I'll go a bit in detail with the action and hopefully that will give you a better insight on it's geometry:
The barrel is fixed onto the frame and it's shaped in such way that the chamber slips over it.
The firearm basic mechanism consists of the following parts:
-sheet metal frame encased in plastic housing
-chamber
-bolt
This excludes small parts and magazine, so until explored we'll just assume they work by magic.
The chamber itself isn't attached to the barrel, so you must think the barrel as a blank of sorts. The chamber is attached to the bolt by a link. Both the bolt and the floating chamber run on rails cut into the frame. We're going to assume that the gun isn't loaded. To load the pistol you'd do what's commonly called "fanning". So to load the gun you would position your hand as if you were going to rapid fire a single action revolver. You sweep the side of your palm over the top while pushing down. When your hand is over the bolt it should push down and by doing so load the chamber.
When fired the gasses in the chamber and barrel expand, and cause the bolt travel back slightly. This expands the previously tight seal between the barrel, chamber, and cartridge hence allowing gasses to fill this newly formed gap. The theory was that this would allow gasses to have more surface which to push and help initiate the reloading action (which it doesn't happen). When the bolt finally starts traveling downwards the gasses have vented and the pressure in the chamber is low to normal, thus preventing the CTA cartridge from traveling backwards when the bolt moves and exposes back of the chamber for reloading. The bolt continues to travel into the grip while pulling the chamber with it. Since the bolt runs on rails it is forced to tilt and land over a new cartridge. In doing so the new cartridge pushes out the spent cartridge and any debri. Because of this function the spent cartridges are tossed in the firing direction. Eventually the recoil forces are spent and the spring pushes the bolt back upwards, hence forcing a cartridge to come off the magazine and be pushed deeper into the chamber by the bolt's upward movement. The chamber and bolt return to their original positions and the firearm can be fired again.
cfe567 No.482171
>>482161
You get what I mean though; a P90 purpose built around a proper, full-sized salt rifle round, thereby bumping it out of the PDW category. 9x25 kinda defeats the point. I gave 5.56 as an example just 'cause it seems economical, and not immediately unworkable.
cfe567 No.482193
>>482171
The problem is at that point you're giving up the defining point of the weapon, and most likely you'll end up with something akin to this abomination.
cfe567 No.482196
>>482193
I've always wanted one of those "abominations" tbqh.
>you're giving up the defining point of the weapon
In exchange for the kind of versatility a meme cartridge can't deliver. It'd fill the role of an m4, only with the advantages that the P90 platform would provide (increased capacity, more barrel, decreased overall length).
cfe567 No.482203
>>482196
You're not getting it. You literally could not use the mag design with anything but the 5.7, or something functionally identical in regards to COAL and case taper. You'd end up with some other proprietary cartridge, in the same marginal performance envelope as 5.7.
That stockset is batty, but it does look cool.
cfe567 No.482221
>>482203
I guess I'm not getting it, I'm unaware of anything about the magazine design that'd render it inherently incompatible with longer casings (doesn't have to be 5.56), other than the fact that the already obnoxious helix bit would get pretty yuge.
cfe567 No.482292
>>482166
I remembered the basics, but thanks for the rundown.
>it is forced to tilt and land over a new cartridge. In doing so the new cartridge pushes out the spent cartridge and any debri.
Now, this is the one part I don't understand. The only think I can imagine is that there is also a rammer in the grip and that rams up the new cartridge into the chamber.
>>482221
>I'm unaware of anything about the magazine design that'd render it inherently incompatible with longer casings
The cartridges have to be straight walled, so you'd have to design them for the weapon. Although CTA cartridges are straight walled, but then their actions tend to be rather funky, so at that point the only thing you keep from the P90 is the magazine's design and placement.
>>482250
How could anyone forget?
cfe567 No.482298
>>482292
Well, it is an unfinished concept.
But yes you're right. It's either that or a device which alters the upwards movement and tilting angle. The solution could be just something simple like two rails that are partially bent over the first layer of rails and an angled feeding notch on the bolt, but we just don't know that yet because the concept hasn't been explored completely.
cfe567 No.482322
>>480811
RIP the original thread, I went all out about details of a fantasy caseless ammo multi-caliber SMG, realized I probably went to far, and didn't come back until the thread was just gone.
cfe567 No.482325
>>482292
I made a mockup of the first out of some scrap. The mag release is detrimental to holding the magazine comfortably and the wire stock is less than desirable. My recommendations would be to use glock magazines, add a proper front grip and a stock almost like a Thompson.
cfe567 No.482328
>>482322
>a fantasy caseless ammo multi-caliber SMG
cfe567 No.482996
YouTube embed. Click thumbnail to play.
With Finns you win! I mean, it looks autistic as fuck, but I can see why it would be good in a bombed out city.
cfe567 No.483217
https://youtu.be/JH9VQGht8CU?t=5m10s
I think you could use this action for a floating chamber gun that fires telescopic ammo. Here is one of my beautiful drawings to demonstrate what I thought up. So it has a fixed bolt and the chamber moves in two rails. There are springs inside the rails that apply a constant downward pressure. The op rod is "hollow", so that the chamber can go down under it. Then the gas piston's rod also acts as a rammer and loads the cartridge, then its spring moves it back to position. Of course it goes through a hole in the end of the op rod, and gets thinner at that part, so it can still push the op rod. The upper receiver only has the barrel and the bolt, everything else is fixed to the lower (including the rails the chamber rides in).
cfe567 No.483219
>>480893
Anyone can create a design with enough trial-and-error
>make initial design
>initial design has issue X
>solve issue X
>this results in issue Y
>solve issue Y
>this results in issue Z
And just repeat until you have something you can live with. As long as the thing you make isn't endangering your life, you can do this indefinitely as long as you have the time and resources. The only thing mechanical engineering experience will do is make it require far less tries and reduce the chances of you losing fingers in the process.
cfe567 No.484777
Alright, I want to share an idea that I've been tossing around in my head. A revolver carbine like the MTs 255, but it has a pump that cycles the cylinder which has grooves like the Webley-Fosbery. Alternatively, the carbine in itself is just an upscaled Webley.
What does /k/ think? Would this be cool or am I just autistic?
cfe567 No.484781
So this design would have been revolutionary like 120 years ago, but I still think it's cool as fuck and wish someone had made it.
The idea is that you slightly pull up on the bolt handle while pulling back to cycle the weapon. Magazine goes through the middle of the action.
cfe567 No.484784
>>483219
>germany in charge of engineering
This explains HK so well.
cfe567 No.484811
>>483219
Are you spying on me? Because that is my flow chart for fixing anything that has more rust than metal on it
cfe567 No.486385
YouTube embed. Click thumbnail to play.
How would you design a ring pistol, /k/?
cfe567 No.486540
>>486385
It's never going to be used at anything more than point blank range anyway, so make it a captive bolt pistol.
>https://en.wikipedia.org/wiki/Captive_bolt_pistol
cfe567 No.486554
>>486385
I probably wouldn't.
cfe567 No.487233
cfe567 No.487241
>>486385
As a 20ga single shot. I'd also give it a handle on the backside, with a lot of metal in it. Severing your customers' fingers wouldn't be healthy for brand image.
cfe567 No.487264
>>486385
Assuming we live in a world where counter law suits from criminals aren't a thing.
It would probably be fuck huge and use a few CB caps or those power loads for a concrete nail gun with a bb placed in front instead of .22 short or lr just for the sake of not having a tower jut out of your hand. Seeing as the ring has so much dangerous shit going on I would say fuck it to any sort of trigger mechanism and just have you punch someone to set them off all at once. It probably won't kill but a punch to the head in even the wrong place will allow you to power walk away from Tyrone as he tries to gather his thoughts and maybe even a small chunk or two of his face. The real issues I see are of course, the non existent capacity for follow up "shots", having absolutely no range, punching someone in a soft area, and the ATF classifying it as a machine gun due to it firing multiple projectiles per "pull of the trigger"
cfe567 No.487269
>>487233
If this website was designed with autistic attention to detail it wouldn't be broken all the damn time. Wait until there is a "down syndrome designs" thread.
cfe567 No.487434
Got an armor design question. Let's say someone had a tech that could make extremely effective ballistic armor, let's just say up to 308 ap no problem. And it was half the thickness of current level 4 tech. And the maker was able to shape things into full knight style suits of armor.
What use would this have in urban combat? What else would you have the wearer arm himself with besides just the suit? Also, if regular riflemen could have a ballistic shield made for them, would you have them carry that over a plate carrier? Check us out on http://8ch.net/tok/res/431.html#601
And drop the armorer a line with your thoughts
cfe567 No.487467
cfe567 No.487901
Here is my contribution to the thread.
8e8565 No.488477
YouTube embed. Click thumbnail to play.
Would an upward-facing barrel make sense in an urban environment?
c7d37f No.488479
I'll just leave this here for you guys.
8cbdd0 No.488482
>>488479
Well shit, I guess all those lefties saying guns are penis fantasies are right.
9242ec No.488506
>>488482
Guns are vaginas. BUllets are penises.
8524bb No.488521
>>487434
This belongs in the QTDDTOT thread not here, but to answer your question a level IV rifle plate is about 18-22mm in thickness compared to 1.5-3mm for medieval plate mail. Even halving that thickness is not going to get you anywhere close.
Even late "munitions" plate mail was designed to survive only low velocity musket balls, and even with modern metallurgy backing it up there's no way you can get it to survive a hardened steel penetrator coming at you at 2,700 fps without increasing the weight to unusable levels.
8033a7 No.488522
>>488479
Is that a Megalosaurus?
1c9be4 No.488814
YouTube embed. Click thumbnail to play.
Would these funky floating chamber designs work just fine with rimless shotgun shells? Not that they would be better than traditional designs, but you could sell such contraceptions to tacticool people who just want something expensive and overcomplicated.
fa8d75 No.491212
>autistic designs
Gatling SMG functioning much like a Dardick would except it's entirely electrically driven and both chamber and barrel share the driveshaft.
And a helical magazine because fuck you, I'm on a roll.
9e6b91 No.491213
>>491212
Fuck, I like it. I take the motor also drives the helical magazine, right? And if it's electric, then might as well go all the way and make it a bullpup. And make the ammo electrically primed too.
7f9b76 No.491218
>>491213
Well, yeah, the ammo is supposed to be electrically primed.
No need to power the magazine though, that there is just going too complex for your own good.
2f9c8b No.494866
I've got an idea:
>40mm AGL like the Balkan
>but it's a floating chamber design
>projectiles are rather long and finned
>they have an internal piston, just like the Fly-K mortar
>because of the floating chamber design the loading mechanism can slide the shells onto the spigot
Basically it would be a fully automatic silent spigot mortar-gun that can't even overheat.
https://www.youtube.com/watch?v=2Owogu_un7s
http://modernfirearms.net/grenade/rus/balkan-e.html
2f9c8b No.494867
>>494866
And as I posted this I've just realized that you'd have to somehow harness the recoil to cycle the gun, as all the gasses are trapped inside the gun. Still, there are plenty of recoil-operated designs, so it's hardly impossible.
7db9d7 No.494868
>>492007
i n f i n i t e a m m o
f119d8 No.494879
>>488506
Saved the original post there, well worth a read.
>>488479
Out of interest are those there as just a 'Hey guys, look what I put on my gun!' thing? Or are you supposed to grab the balls and use them as a forwards grip? Because that last one does not sound like fun.
907140 No.499109
YouTube embed. Click thumbnail to play.
I think I've found /ourguys/.
75ec01 No.499214
With the possibility of the Hearing Protection Act being passed, I've been thinking of how to best take advantage of the new market opportunities the deregulation of suppressed weapons will present.
As with any market opportunity, one must ask themselves what the largest problem out there without an adequate solution, that is the key to initial success (IMO). So what is the biggest problem with suppressed weapons as they exist today? In my opinion it is the fundamental compromise of needing power from a subsonic round. After all, what's the point of having a suppressor if the crack of a supersonic bullet negates your efforts at sound reduction?
So what is the answer? There's only one commercial subsonic round on the market today that's common enough to be considered cheap, the venerable .45 ACP. Of course, .45 isn't powerful enough for a carbine or rifle and even the largest subsonic niche/wildcat cartridges (.300 Memout, .458 SOCOM) are still less powerful than the lamest supersonic pistol sized carbine rounds in terms of energy. Thus, there's a niche for a 2,500+ joule, subsonic cartridge in the suppressed market.
So how do you get that much energy from such a sloe bullet? Duh, mass. Enter the 800 grain .50 BMG bullet. Tale this and place it in an available, SAAMI accepted case from a large manufacturer and you've got yourself a stew going. My choice after just a few hours of research would be a Winchester Short Magnum case, special ordered without a neck. Since one only needs ~70-75 grains of powder to propel an 800gr .50 BMG bullet to the 1,100ft/s barrier, there is more than enough internal volume to accommodate the bullet and powder load even with a necked down case while still staying within the overall length of a 30-06 length action design. You'd have rifl$-class power with a truly quiet report.
What does /k/ think?
3c164d No.499217
>>499214
Sounds like something that needs some research.
>Optimal barrel length to keep velocity lower than super sonic.
>If exagerated porting of the barrel (similar to the VSS/VAL) is needed to keep velocity down.
>If faster burning powder would be beneficial (similar to .300 blackout).
Are you going for bolt or semi because I think a 700grain .50bmg projectile will lead to some length issues?
6510ad No.499291
>>499214
"What is .510 Whisper?"
I'll take "Re-Inventing the wheel" for $800, Alex
75ec01 No.499335
>>499291
I had no idea that existed. While I feel a little stupid for not knowing this already existed, I also feel vindicated by the fact that my concept is so fundamentally sound that someone is making almost the exact same thing on a commercial scale.
4b2e63 No.499408
>>499109
>2 minutes of build up
>It's the size of a fucking buckler
>No ballistic protection of any sort
I thought it couldn't get better until the "rescuing the wounded" bit
a13699 No.499423
>>499408
Oh yes, that "rescuing the wounded" is "help the fucking children"-tier. Here is some advertisement: http://archive.is/e0LSE
a23d51 No.499842
>>484777
Holy trips confirm, it must be so
0e6fb4 No.499849
>>499109
Whats the level of protection?
0a07b7 No.505735
>>499849
I wonder, would replacing mortars with rockets work? Imagine the same kind of shells, just with a simple rocket motor in the tails. That way you could launch them from a lightweight spigot-mortar like device, therefore you wouldn't need a barrel. The downside is that you couldn't vary the amount of charges, so you'd be forced to "go full power" with every shot.
aef296 No.505844
>>481005
>bullpup smg
For what purpose?
a94dec No.505849
>>505844
To confuse random design bureau students out of Russia.
eef68a No.505873
>>505844
Artist was just autistic and couldn't draw a fluted barrel to save his life.Lack of a grip, though, that's due to poor choice in reference.
b0cc28 No.505876
>>505873
heh didn't notice the shit art had missing grip before. in the picture it's just hidden in the shadow of his pants. i can see the hogue pleasure ribs.
2140ac No.511347
How about a bullpup GPMG with a tripod similar to a Lafette mount? If the tripod has a periscopic sight and a trigger, then the only difference for the gunner and his assistant is that the belt is closer to them.
b635e7 No.511359
>>505844
In case anyone wants a slightly longer barrel. What he posted is retarded, people would blow fingers off all the time.
17dd12 No.516704
Why weren't there any new wheeled machine gun mounts after ww2? Would it be autistic to bring them back to the modern battlefield?
a905f5 No.516709
>>516704
Probably weight/volume.
e30f0a No.516716
>>516709
It could also be the transition between trench warfare and a more mobile, fluid form of war, at least coming from the great powers. Less powerful forces with no air support still have to engage in some form of trench warfare, so I guess they could still have a place, but I'm not so sure.
17dd12 No.516833
>>516709
I don't think that a modern wheeled mount would weight that much more compared to a modern tripod. Especially if you don't add a shield.
>>516716
But why would you switch from wheels to legs if warfare is more mobile?
e30f0a No.516911
>>516833
Only if you were a poorfag with poor logistics and mobility. Some Novorossians put a KPVT on a wheeled mount.
63f5f3 No.517028
>>516911
Do you mean that the infantry doesn't need wheels to move around a machine gun that usually weights more than 30kg with the mount, because they can put it on a car? Because the wheels aren't for marching in this case, but to quickly reposition the machine gun during a firefight. You could put an ammo can with 1000+ rounds on the wheeled mount and two people could still just grab it and run to a new position.
cb259e No.517037
>>517028
>switch from wheels to legs
Legs are lighter, more maneuverable and if you can do without a bipod you generally will go out of your way to remove that thing.
7c3284 No.518671
>>484777
It can be both cool and autistic
b178c0 No.520716
Could a modern Bren gun be of much use? I don't mean in terms of the action, but as in an LMG with a top feeding mag that can be quickly swapped between bursts by the assistant. Eh?
